Threaded entry: Metric
Color: Black and grey
Working temperature: -40℃-100℃,the item can also endure 120℃ instantly
Protection: IP68
Standard: IEC698
ITEM.NO. |
Threaded entry metric (mm) |
Cable range φ (mm) |
D1 |
Panel mounting hole (mm) |
L1 | L3 |
A (mm) |
---|---|---|---|---|---|---|---|
WFMG-12 | M12×1.25 | 7.6-4.6 | 12 | 12.5 | 8.5 | 19 | 18 |
WFMG-16 | M16×1.5 | 10-6 | 16 | 16.5 | 15 | 22 | 22 |
WFMG-20 | M20×1.5 | 14-9 | 20 | 20.5 | 15 | 27 | 27 |
WFMG-25 | M25×1.5 | 19-13 | 25 | 25.5 | 15 | 33 | 33 |
WFMG-32 | M32×1.5 | 25-18 | 32 | 33 | 15 | 41 | 41 |
WFMG-40 | M40×1.5 | 30-24 | 40 | 41 | 20 | 50 | 50 |
WFMG-50 | M50×1.5 | 39-30 | 50 | 51 | 22 | 62 | 61 |
WFMG-63 | M63×1.5 | 48.5-40 | 63 | 64 | 25 | 75 | 75 |
